INSPIRE LASER RAY KIT SV144B
This kit contains a laser ray box with five independent laser modules, supplied with eight printed magnetic template sheets. Thin magnetic sheet are attached to the bottom of laser housing and lens accessories, thus allowing easy positioning of template sheets on a magnetic board for the demonstration of various experiments. The template sheets include demonstrations of the functioning of the human eye and refracting telescopes etc. A magnetic whiteboard is available separately if required.
- Magnetic mounting of the laser, lenses, and templates allows vertical demonstration on a whiteboard or metal screen.
- 5-Red laser beam (peak wavelength 635 nm).
- Includes eight magnetic templates.
- Full range of lens accessories.
- Supplied with a high-quality carry case.
Exp-1 Principle of the Galileo telescope.
Exp-2 Working of the human eye (normal, far sighted and short sighted vision).
Exp-3 Principle of the Kepler telescope.
Exp-4 Principle of the camera.
Exp-5 Principle of spherical aberration energy.
Exp-6 Principle of periscope.
- Optical Aberrations
- Human Vision and Eye
- Function
- Galileo telescope
- Kepler telescope
- Periscope
| Code | Description | Qty. |
| C14741 | Magnetic Board with Pipe Support | 1 |
| SV273 | Laser Ray Box with Adaptor | 1 |
| CB503 | Biconvex Lens No. 1 | 1 |
| CB504 | Biconvex Lens No. 2 | 1 |
| CB505 | Biconvex Lens No. 3 | 1 |
| CB506 | Biconvex Lens No. 4 | 1 |
| CB507 | Biconcave Lens No. 5 | 1 |
| CB513 | Plain Mirror No. 6 | 1 |
| CB511 | Concave Mirror No. 7 | 1 |
| CB512 | Concave Mirror No. 8 | 1 |
| CB509 | Plano Convex Lens No. 9 | 1 |
| CB515 | Prism No. 10 | 1 |
| CB514 | Rectangular Plain Parallel Plate No. 11 | 1 |
| CB516 | Optical Fiber No.12 | 1 |
| CB510 | Plano Concave Lens No. 13 | 1 |
| CB508 | Plano Convex Lens No. 14 | 1 |
| R11580 | Briefcase AL | 1 |
| CD1197B | Work Sheets (Set of 8) | 1 |
